ICON 2016-2023 Nissan Titan XD, 3″ Lift, Stage 1 Suspension System

Description

The 2016 Nissan Titan XD is an all new truck with a heavy-duty build that’s aimed to blend the lines between ½ ton efficiency and ¾ ton capability. With this in mind, ICON Vehicle Dynamics has developed a complete suspension system designed from the ground up for improved performance on and off-road, increased wheel travel over stock, and the best ride quality on the market. The Stage 1 system includes ICON 2.5 Series coilovers, 2.0 Aluminum Series rear shocks, rear lift blocks, and u-bolts. These products feature high-quality components such as ICON-designed coil springs, precision machined internals, FK Rod End bearings, and a vehicle-specific shock tune that translates to a ride quality that is second to none. The ICON Vehicle Dynamics 2016-UP Nissan Titan XD Stage 1 suspension system is an excellent choice for drivers looking to enhance the capabilities of their pickup on the road as well as in the dirt.

Features & Benefits:

• Fits 2WD / 4WD applications
• Increased ride quality over stock with no change in towing capacity
• Approximately 32% increased front wheel travel over stock
• Adjustable coilovers provide 2.5-3″ of lift height
• Vehicle specific tuned front and rear shocks for superior shock damping and control
• 6061 aircraft grade aluminum CNC machined components
• Corrosion resistant CAD plated coilover shock body with 7/8″ shaft
• Corrosion resistant anodized shock body with 5/8″ shaft (2.0 Aluminum Series shocks)
• FK Rod End bearings for extended longevity and minimal deflection
• 100% bolt-on system

NOTES:

• OEM Wheels & Tires Fitment: Yes
• Recommended Aftermarket Wheels: ICON Alloys – 17×8.5″ w/ 4.75” Backspace / 0mm Offset
• Recommended Aftermarket Wheels: ICON Alloys – 18×9″ w/ 5.00″ Backspace / 0mm Offset
• Recommended Aftermarket Wheels: ICON Alloys – 20×9″ w/ 5.00″ Backspace / 0mm Offset
• Recommended Aftermarket Tires: 33″ x 11.50″ (Larger tires may fit but fender trimming and modifications will be required.)
• APPLICATION NOTE #55: Shocks Are Fully Serviceable. Coilover Heights Indicated Are For A Stock Equipped Vehicle
• APPLICATION NOTE #115: Lift Heights Based On 4Wd Crew Cab Diesel
• Ships in multiple boxes

Components:

• 81021 (QTY: 1) | 16-23 TITAN XD 2.5 IR COILOVER KIT
• 86535 (QTY: 2) | 16-23 TITAN XD 0-1.5″ REAR 2.0 VS IR
• 88700 (QTY: 1) | 16-23 TITAN XD 9″ U-BOLT KIT
• 191201 (QTY: 1) | 1″ CAST BLOCK KIT

ICON 2016-2023 Nissan Titan XD, 3″ Lift, Stage 1 Suspension System | SKU: K83031
